High conversion rate, new energy products 110W 120
original price: 1,68 USD
jianrong gong
Contact person
Basic Information
| Place of Origin | Jiangsu China (Mainland) |
|---|---|
| Brand Name | HZ |
| Model Number | HZ110w54M-HZ145W54M |
| Size | 1200*808*30 |
| Number of Cells | 54pcs |
| Max. Power | 145W |
| Material | Monocrystalline Silicon |
Mono Solar Panels 125(110W-145W) 54pcs Characteristics Modol110W-54M120W-54M130W-54M140W-54M145W-54MOpen circuit voltage(Voc)32.6V32.8V33.00V33.20V33.40VOptimum operating voltage(Vmp)26.10V26.40V27.50V27.60V27.80VShort circuit current(Isc)4.77A4.90A5.15A5.52A5.68AOpptimum operating current(Imp)4.21A4.55A4.73A5.07A5.21AMaximum power at STC(Pm)110W120W130W140W145W Cell Monocrystalline silicon solar cells 125*125mm No of cells and connections 54(6*9) Dimension of module(mm) 1200*808*30 Weight 12KG Operating temperature -40 to +85°C Maximum system voltage 1000V DC NOCT 45°C±2°C Current temperature coefficient %/K 0.06±0.01 Voltage temperature coefficient Mv/K -(155±10) Power temperature coefficient %/K -(0.5±0.05) Type of output terminal Junction box Cable (4.0mm2)LAPP Symmetrical length 900mm Connection Type IV Production Line: Solar panel structure: Glass: Junction box: Carton Packaging: solar power system(off-grid)
Delivery terms and packaging
Packaging Detail: Carton Packaging Delivery Detail: 20-30 days after the 30% deposit to arrivecompany's account
Port: Shanghai
Payment term
Letter of credit
Telegraphic transfer
-
Payment Methods
We accept:
